Cool Limited 5.9\ 1080P LS059T1SX01 1080*1920 LCD screen display with HDMI MIPI driver board with MIPI connector for VR product 3D printer

Cool Limited 5.9\ 1080P LS059T1SX01 1080*1920 LCD screen display with HDMI MIPI driver board with MIPI connector for VR product 3D printer printer systems Rating: 4.0 out of 5

Best Laser Printer Machine Sale Choice Collections provide printer pen,thermal printer Cool Limited 5.9\ 1080P LS059T1SX01 1080*1920 LCD screen display with HDMI MIPI driver board with MIPI connector for VR product 3D printer. Get Discount Now! Only US $81.04/piece at this time. Hurry buy Now before back to normal price! Normal price US $94.23 or you can Check price now. Dont waste your time. Buy Now only in Trusted Seller Store!

Excellent5.9" 1080P LS059T1SX01 1080*1920 LCD screen display with HDMI MIPI driver board with MIPI connector for VR product 3D printer

please note: the connection between the screen and board is quite delicate . do not connect to a wrong side. please see video

Panel Model LS059T1SX01 Luminance400 cd/m⊃2; (Typ.)

Panel SizeContrast Ratio 1000:1 (Typ.) (Transmissive)

Panel Type CG-Silicon , LCM Good View at Symmetry

Number of Pixel 1080(RGB)×1920 (FHD) Response Speed TBD ms

Arrangement RGB Vertical Stripe Viewing Angle 80/80/80/80 (Typ.)(CR≥10)

Dot Pitch(W×H) 0.0225×0.0675 mm Operating Mode Normally Black, Transmissive

Pixel Pitch(W×H) 0.0675×0.0675 mm Chromaticity Wx:0.300; Wy:0.320

Active Viewing 72.9(W)×129.6(H) mm Support Color 16.7M (8-bit)

Overall Dim. 76.2(W)×139.1(H) mmGamut70% NTSC (CIE1931)

Bezel Opening 73.9(W)×130.6(H) mm White Variation 1.43 (Max.)(9 points)

Overall Depth 1.65 mm Input Current 16.9/17.0/12.0mA (Typ.)(IDDIO/ISP/ISN)

Form Shape Flat Rectangle Display Input Voltage 1.8/5.6/-5.4V (Typ.)(VDDIO/VSP/VSN)

Orientation Portrait type Signal Interface MIPI (4 data lanes)

Aspect Ratio(W:H) 9:16 Pin Pitch 0.4 mm

Lamp Type WLED Pins 30 pins

Amount7S2P Physical Type Connector

Position Edge light type Lamp Shape 2 strings

Input Voltage 21.0V (Typ.) Input Current 20mA (Typ.)

Backlight Driver No
